Features:
1.7” TFT LCD monitor: bigger, better monitor, icon-display menu for easier operation and settings.
2.Motorized Joystick: A motorized joystick with auto tracking mode is adopted for easier operation.
3.Motorized Chinrest: Operator can easily adjust the chinrest with switch located on the operator side and enables speedy reading.
4.Tilt Screen:Tilt screen function that allows wide variance of access whether the operator is setting or standing.

Specification:

Range of measurement:
1.Vertiex distance (VD): 0, 12, 13.75, 15mm
2.Sphere (S):-20.00~+20.00D (VD=12mm, 0.12 or 0.25D steps)
3.Cylinder(C):-8~+8D (0.12D or 0.25D steps)
4.Axis(A):0-180°(Step 1°)
5.Pupil Distance(DP): 45-88mm
6.Minimum Pupil Diameter: Φ2.00mm
Keratometer
1.Radius of Curvature: 5.0~10mm
2.Corneal Refractometry: 33.00~67.50D
3.Corneal Astigmatism: 0.00~8.00D
4.Corneal Diameter: 2.0~14.0mm
5.Axis: 1~180° (increment: 1°)
6.Memory of data: 10 measure value for each right and left eye
Others
1.Printer: Thermal printer
2.Chart: Follow up colorful fogging chart system
3.Display: 7” TFT LCD
4.Power: 220V, 50/60Hz
5.Dimensions: 478(L)*268(W)*472(H)mm
6.Net Weight: 20kgs
Auto Refrac-Keratometer VS-1650
Auto Refrac-Keratometer VS-1650
Features:
1.7” TFT LCD monitor: bigger, better monitor, icon-display menu for easier operation and settings.
2.Motorized Joystick: A motorized joystick with auto tracking mode is adopted for easier operation.
3.Motorized Chinrest: Operator can easily adjust the chinrest with switch located on the operator side and enables speedy reading.
4.With high quality of hexagon prism and highly sensitive CCD, it provides excellent accuracy and reliability.

Specification:

Range of measurement:
1.Vertiex distance (VD): 0, 12, 13.75, 15mm
2.Sphere (S):-20.00~+20.00D (VD=12mm, 0.12 or 0.25D steps)
3.Cylinder(C):-8~+8D (0.12D or 0.25D steps)
4.Axis(A):0-180°(Step 1°)
5.Pupil Distance(DP): 45-88mm
6.Minimum Pupil Diameter: Φ2.00mm
Keratometer
1.Radius of Curvature: 5.0~10mm
2.Corneal Refractometry: 33.00~67.50D
3.Corneal Astigmatism: 0.00~8.00D
4.Corneal Diameter: 2.0~14.0mm
5.Axis: 1~180° (increment: 1°)
6.Memory of data: 10 measure value for each right and left eye
Others
1.Printer: Thermal printer
2.Chart: Follow up colorful fogging chart system
3.Display: 7” TFT LCD
4.Power: 220V, 50/60Hz
5.Dimensions: 478(L)*268(W)*472(H)mm
6.Net Weight: 20kgs
Auto Refrac-Keratometer VS-1680
Auto Refrac-Keratometer VS-1650
Feathers:
1. With Auto-tracing feature, operator can adjust the focus and alignment in up and down directions.
2. With Auto video taping feature, operator can take measurements automatically once equipment obtains satisfactory focus and alignment.
3. With Servo Chin-Rest, operator can adjust height of Chin-rest easily.
4. Display is tilt-adjustable.
5. Printer has a paper auto-cut feature.

Specifications:
Refractometer
1.Vertiex distance (VD): 0, 12, 13.75, 15mm
2.Sphere (S):-20.00~+20.00D (VD=12mm, 0.12 or 0.25D steps)
3.Cylinder(C):0.00~+/-10.00D (0.12 or 0.25D steps)
4.Axis(A):1-180°(Step 1°)
5.Cylinder Form: -,+,+/-
6.Pupil Distance(DP): 30-85mm
7.Minimum Pupil Diameter: Φ2.00mm
8.Measuring time: 0.5sec
Keratometer
1.Radius of Curvature: 5.0~10mm
2.Corneal Refractometry: 33.00~67.50D
3.Corneal Astigmatism: 0.00~-15.00D
4.Corneal Diameter: 2.0~12.0mm
Others
1.Printer: Thermal printer
2.Power save: 5, 15Min.
3.Display: 5.7” TFT LCD
4.Auto Tracing function range:±mm(up and down direction only)
5.Power: AC100~240V, 50/60Hz/90W
6.Dimensions: 480(L)*270(W)*445(H)mm
7.Net Weight: 17kgs
8.Jaw Panel: Max 55mm
Auto Refrac-Keratometer VS-1810
Feathers:
1. Adopt embeded micro-process and fast image process techinique, which makes the masurement more quickly.
2. Quick measurement for diopter of MIN. Pupil size.
3. New design of colorful screen(8” TFT/LCD）
4. Auto fog chart.
5. Pupil distance auto measured available.
6. Auto measurement.

SPECIFICATIONGS:

Refractometer
1.Vertiex distance (VD): 0, 12, 13.75, 15mm
2.Sphere (S):-20.00~+20.00D (VD=12mm, 0.12 or 0.25D steps)
3.Cylinder(C):0.00~+/-10.00D (0.12 or 0.25D steps)
4.Axis(A):0-180°(Step 1°)
5.Cylinder Form: -,+,+/-
6.Pupil Distance(DP): 10-85mm
7.Minimum Pupil Diameter: Φ2.00mm
Keratometer
1.Radius of Curvature: 6.9~9.5mm
2.Corneal Power: 33.00~67.50D
3.Corneal Astigmatism: 0.00~-15.00D
Others
1.Display: 8” TFT LCD  (touch screen)
2.Auto Tracing function range:±mm(up and down direction only)
3.Power: AC220/AC110 50/60Hz 60VA
4.Dimensions: 500(L)*250(W)*450(H)mm
5.Net Weight: 13kgs












Auto Refrac-Keratometer VS-1860
