FEATURES:
1. By the way of double locating, it would correct errors automatically. 2. Offering more clear and share pictures. 3. Increase the picture density; there are 8 icons in one line. 4. The charts are bigger; size 330mm*225mm(in 5m refraction) 5. Projected by wireless remote controller. 6. Able to project the charts one by one. 7.Standard accessories, the metal board is covered by bias material.
MAIN TECHNICAL INDEXES
1. Projection distance: 2-6m
2. Projection magnification: 30 × (in 5m refraction)
3. Projection size: 330 × 225mm, ø275mm (in 5m refraction)
4. Numbers of charts: 33
5. Chart change-over: 3 frame / sec
6. Numbers of masks: open 1, horizontal line 3, vertical line 8, single isolation 16, r and g 1
7. Tilt range: 10 ° horizontally as well as vertically
8. Projection lamp: 6V 20W (halogen lamp)
9. Automatic shut-off mechanism: 5 minutes
10. Electricity: AC 110V/60HZ or 220V/50HZ
11. Power consumption: 65W
12. Dimension: 196(W)×292(L)×234(H)mm
13. Weight: 6.5kgs
